Structural Fireman Suit
Nomex Structural &External fireman suit
LV-FS203 Nomex Structural &External fireman suit is SOLAS and EN469:2020 approved firefighter's protective clothing, comprising jacket and trousers, made of nomex fabric in 4 layers. Firefighter Accessories for Marine & Offshore • Protective clothing for firefighters • High heat and flame resistance • Designed for comfort and durability in extreme conditions
Nomex navy blue Turnout Gear /Fire fighting suit
Model:LV-FS203®
Description
LVIN FIRE Firefighter clothing is designed to protect firefighters against the hazards and chemical exposure of fire fighting in most extreme environments. Today’s fire fighting clothing must meet tough safety standards including European Standard EN469:2020,comply with NFPA. Other requirements of fireman clothing include being: thermally insulated, water repellent, breathable, flexible in nature, light-weight, high-impact, puncture, and tear resistant.
LV-FS203®ergonomically designed that gives the ultimate in fit and comfort for the maximum number of body types. The coat features increased upper sleeve fullness and protected thumb area function.Similarly, the trouser features articulated knees and convex seams as well as shaped seaming to provide added flexibility when climbing, crawling, and bending.
Features
- All layers are breathable and with comfortable linings reduce the build up of heat.
- Built-in belt over the shoulder eliminates the shoulder seam and make a smoother line with greater comfort when wearing breathing apparatus.
- The short style coat is designed with ergonomic fit, the trouser measurements provide adequate overlap, there is no any gap between coat and trousers when rescuing.
- Tape configuration give extra reflective area also emphasizing style lines. The tape is breathable and stitched with meta-aramid braid.
- Fully articulated three dimensional ergonomic knee shaping which goes through all layers. Very flexible reinforcement fabric used.
Application
LV-FS203® widely used in the following sites:
•Fire fighting rescue •Search and rescue
•Aircraft/airport rescue • Wildland fire suppression
•Confined space rescue •Building collapse
•High angle rope rescue •Swift water rescue
•Trench rescue •Tool hoisting
•Shipboard and military fire and rescue •Other hazardous environments
Performance Specifications
Technical Parameters | Model No: LV-FS203® |
Standard :CE ＆EN,ISO approved | |
Outer shell material layer: 93% Nomex/5% Para Aramid/2% Anti-stastic | |
Moisture barrier layer : aramid felt with PTFE membrane | |
Thermal barrier layer: aramid | |
Comfortable lining : plain poplin | |
Net weight: ≤3.22Kg/set | |
Damaged length: ≤10cm | |
Renewal burning time: ≤2s | |
TPP value: ≥35.7cal/cm | |
Hydro-static pressure: ≥17000pa | |
Color:navy blue,orange, yellow/khaki for option | |
OEM＆ODM: original manufacture / logo and pattern customization | |
Packing: one intactly packaged, 5 sets into one carton |
